Details

Built to go faster.

Sizes:
Frame	XS	S	M	ML	L	XL
Seat tube length (mm)	425	445	470	500	530	560
Seat tube angle (deg)	74.5	74	73.5	73	73	72.5
Top tube length (mm)	520	535	550	565	580	600
Head tube length (mm)	120	130	145	165	185	200
Head tube angle (deg)	71	72.25	73	73	73	73
Fork rake (mm)	45	45	45	45	45	45
Trail (mm)	72.1	64	59.2	59.2	59.2	59.2
Wheelbase (mm)	976	977	980	991	1006	1020
Chain stay length (mm)	405	405	405	405	405	405
BB drop (mm)	72	69.5	69.5	67	67	67
Stack (mm)	517	528	545	562	581	596
Reach (mm)	376	383	388	393	402	412
Stand over (mm)	703	722	743	771	798	822
Handlebar width (mm)	400	400	420	420	440	440
Stem length (mm)	80	90	100	110	110	120
Crank length (mm)	170	170	172.5	172.5	175	175
Wheelsize	700C	700C	700C	700C	700C	700C

Specs

Pedals	Sold Seperately
Fork	Advanced-grade composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc
Hubs	Giant P-R2 Disc wheelset, 12mm thru-axle
Rims	Giant P-R2 alloy Disc wheelset
Stem	Giant Contact Aerolight
Chain	KMC X12L-1
Frame	Advanced-grade composite, 12x142mm thru-axle, disc
Tires	Giant Gavia Course 1, tubeless, 700x25c (28mm), 60 TPI, folding
Brakes	Shimano 105 Di2 hydraulic, Giant MPH rotors [F]160mm, [R]140mm
Saddle	Giant Approach
Spokes	Sapim stainless
Crankset	Shimano 105, 34/50 XS, S:170mm, M, M/L:172.5mm, L, XL:175mm
Seatpost	Giant Variant, composite, -5/+15mm offset
Shifters	Shimano 105 Di2
Handlebars	Giant Contact
Tape/Grips	Stratus Lite 2.2
Brake Levers	Shimano 105 Di2
Bottom Bracket	Shimano BB71, press fit
Rear Derailleur	Shimano 105 Di2 RD-R8150
Front Derailleur	Shimano 105 Di2 FD-R8150
Accessories & Extras	tubeless prepared, 33mm max tire size
Cassette/Freewheel	Shimano 105, 12-speed, 11x34

* Subject to change without notice.
